Air Handling Equipment
Blower FanManufacturer in Gurgaon, India
High-pressure centrifugal air movement for industrial applications
01 / 08
Quick answer
What is a blower fan?
A centrifugal blower moves air at high pressure using a rotating impeller in a scroll housing. U.S.T Enterprises manufactures ID (induced draft), FD (forced draft) and general-purpose centrifugal blowers from 0.5 to 50 HP, up to 52,000 CFM and 85% efficiency, for dust collection, boilers, furnaces, dryers and ventilation.
Blower Fan - overview
High-pressure Industrial Blower Fan manufacturer in India. Centrifugal blower fan designed for high-pressure air movement and ventilation applications. Features backward-curved impeller blades for maximum efficiency, robust construction for continuous operation, and variable speed control for precise airflow management.
- Motor Power
- 0.5-50 HP (0.37-37 kW)
- Air Flow Rate
- 200-52000 CFM (340-88400 m³/h)
- Static Pressure
- 2-10 inches WG (500-2500 Pa)
Key features
- High-efficiency backward-curved impeller design
- Heavy-duty cast iron or aluminum construction
- Direct drive motor mounting for reliability
- Dynamically balanced impeller for vibration-free operation
- Thermal protection with auto-restart capability
- Double-shielded shaft bearings for extended life
- Compact design for space-efficient installation
- Wide voltage and frequency range compatibility
- Dust-proof shaft seal for contamination protection
- Sound-dampened housing for reduced noise levels
Talk to an engineer about this machine
Share your capacity and application - we reply within 24 hours.
Direct manufacturer
Built in IMT Manesar since 1970
Made to your spec
Capacity, MS / SS304 / SS316, automation
Pan-India installation
Erection, commissioning & training
Factory pricing
No middlemen, GST invoice
Datasheet
Blower Fan technical specifications
Specifications vary by model. Custom sizes and capacities are available on request.
Last reviewed:
| Motor Power | 0.5-50 HP (0.37-37 kW) |
|---|---|
| Air Flow Rate | 200-52000 CFM (340-88400 m³/h) |
| Static Pressure | 2-10 inches WG (500-2500 Pa) |
| Fan Speed | 1450-3600 RPM |
| Impeller Diameter | 200-1000 mm |
| Inlet Size | 150-800 mm |
| Outlet Size | 125-750 mm |
| Voltage | 220V/380V/415V, Single/Three Phase |
| Frequency | 50/60 Hz |
| Noise Level | 58-85 dB(A) |
| Operating Temperature | -20°C to +80°C |
| Material | Cast Iron/Aluminum housing, Steel impeller |
| Efficiency | Up to 85% |
| Weight | 50-2500 kg (model dependent) |
Where it works
Applications & industries served
- Dust collection
- Boilers & furnaces
- Pneumatic conveying
- Dryers
- Ventilation
Part of our solutions for
Answers
Frequently asked questions about Blower Fan
What types of industrial blower fans do you manufacture?
We manufacture centrifugal blowers including ID (Induced Draft) fans, FD (Forced Draft) fans, and general-purpose blowers with backward-curved impellers from 0.5 to 50 HP, up to 52,000 CFM capacity.
Which applications use your centrifugal blower fans?
Our blowers serve dust collection systems, furnace/boiler draft control, pneumatic conveying, industrial ventilation, drying systems, fume extraction, and cooling applications across manufacturing plants.
What HP industrial blower do I need for my application?
The required HP depends on airflow (CFM) and static pressure (Pa). A 5 HP blower handles small dust collectors, while 20-50 HP units serve large furnaces and pneumatic conveying systems. Contact us for application-specific sizing.
How much does a 5 HP centrifugal blower cost?
Pricing depends on HP, CFM capacity, material (MS/SS), and impeller design. Manufactured at our Gurgaon facility, we offer direct factory pricing. Contact us for a model-wise quotation.
